Referencia: R8R47A
Marca: HP
ARUBA ION 1430 16G CPNT
HPE Networking Instant On 1430 16G Switch - Conmutador - sin gestionar - 16 x 10/100/1000 - sobremesa, montaje en rack, montaje en pared - BTO
Alimentación | |
Dispositivo de alimentación | Fuente de alimentación eléctrica |
Potencia suministrada | 500 vatios |
Voltaje necesario | CA 120/230 V (50/60 Hz) |
Consumo eléctrico en funcionamiento | 30.6 vatios |
Dimensiones y peso | |
Anchura | 44.2 cm |
Profundidad | 30.48 cm |
Altura | 4.39 cm |
Peso | 5.02 kg |
Diverso | |
Cumplimiento de normas | Certificado FCC Clase A, CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, Laser Class 1, UL 60950-1 Second Edition, EN 60825, VCCI Class A, EN 60825-1:2007, CAN/CSA C22.2 No. 60950 Second Edition, IEC 60825-1:2007 Class 1, EN 55022/CISPR 22 Class A, RFC1213, RFC1493, RFC2674, IEC/EN 60950-1, RFC768, RFC2460, RFC2925, RFC1591, RFC783, RFC792 |
Expansión / Conectividad | |
Interfaces | 48 x 10/100/1000 Base-T RJ-45 PoE+ ¦ 4 x 1/10Gbit LAN SFP+ ¦ 1 x USB-C consola ¦ 1 x USB Type A |
Garantía del fabricante | |
Servicio y mantenimiento | Garantía limitada - de por vida |
General | |
Tipo de dispositivo | Conmutador - 52 puertos - Gestionado |
Tipo de caja | Flujo de aire de lado a lado montaje en rack 1U |
Subtipo | 10 Gigabit Ethernet |
Puertos | 48 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+ |
Alimentación por Ethernet (PoE) | PoE+ |
Presupuesto PoE | 370 W |
Rendimiento | Capacidad de conmutación: 176 Gbps ¦ Capacidad: 98.6 µs ¦ Latencia (1 Gbps): 1.9 µs ¦ Latencia (10 Gbps): 1.8 µs |
Capacidad | Interfaces virtuales conmutadas (SVI): 16 ¦ Entradas ARP: 1024 ¦ IPv4 routes (Unicast): 512 ¦ Rutas IPv6 (Unicast): 512 ¦ Grupos IGMP: 512 ¦ Grupos MLD: 512 ¦ Entradas ACL IPv4 (entrada): 256 ¦ Entradas ACL IPv6 (entrada): 128 ¦ Entradas ACL MAC (entrada): 256 |
Tamaño de tabla de dirección MAC | 8.192 entradas |
Protocolo de direccionamiento | IGMPv2, IGMPv3 |
Algoritmo de cifrado | SSL |
Método de autentificación | Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
Características | Control de flujo, soporte BOOTP, soporte ARP, soporte VLAN, soporte DiffServ, soporte IPv6, soporte SNTP, sFlow, compatible con MSTP, compatible con TFTP, rastreador MLD, Compatible con LACP, con LLDP, control de acceso mediante puertos, cliente DHCP, Energy Efficient Ethernet, MIB, NAC, NDP, compatibilidad con SNMP, ICMP, EntityMIB, cliente DNS, LLDP-MED, UDP, RSTP, direccionamiento IPv6 |
Cumplimiento de normas | IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.3at, IEEE 802.3az |
Procesador | 1 x ARM A9: 1.016 GHz |
Memoria RAM | 4 GB DDR3 SDRAM |
Memoria Flash | 16 GB |
Parámetros de entorno | |
Temperatura mínima de funcionamiento | 0 °C |
Temperatura máxima de funcionamiento | 45 °C |
Ámbito de humedad de funcionamiento | 15 - 95% (sin condensación) |
Ámbito de humedad de almacenamiento | 15 - 90% (sin condensación) |
