Referencia: R8N85A
Marca: HP
ARUBA 6000 48G CL4 4SFP CPNT
HPE Aruba 6000 48G Class4 PoE 4SFP 370W Switch - Conmutador - Gestionado - 48 x 10/100/1000 (PoE+) + 4 x Gigabit SFP - flujo de aire de lado a lado - montaje en rack - PoE (370 W)
Alimentación | |
Dispositivo de alimentación | Fuente de alimentación eléctrica |
Voltaje necesario | CA 100-240 V (50/60 Hz) |
Dimensiones y peso | |
Anchura | 44.25 cm |
Profundidad | 35.05 cm |
Altura | 4.395 cm |
Peso | 4.7 kg |
Diverso | |
MTBF (tiempo medio entre errores) | 65.3 años |
Cumplimiento de normas | EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, EN 61000-3-3, ICES-003 clase A, VCCI Class A, CNS 13438 Class A, KN35, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, AS/NZS CISPR 32 Class A, KN32 Class A, IEC/EN 61000-4-11, IEC/EN 61000-4-2, UL 62368-1 Second Edition, IEC/EN60950-1:2006 +A11:2009 +A1:2010 +A12:2011 +A2:2013, EN 55032:2015 Class A, CISPR 32:2015 Class A, UL 62368-1, EN 55035, CISPR 35, IEC/EN 60825-1:2014 Class 2, IEC/EN 62368-1, UL 62368-1 Third Edition, CAN/CSA C22.2 No. 62368-1 Third Edition, CAN/CSA C22.2 No. 62368-1 Second Edition, FCC CFR47 Part 15 B Class A 2018 |
Tipo de precios | BTO |
Expansión / Conectividad | |
Interfaces | 24 x 10/100/1000 Base-T RJ-45 370 W ¦ 2 x 10 Gigabit Ethernet / 10 Gigabit Ethernet SFP+ SFP+ ¦ 2 x 10GBase-T RJ-45 |
Garantía del fabricante | |
Servicio y mantenimiento | Garantía limitada - de por vida |
General | |
Tipo de dispositivo | Conmutador - 24 puertos - L3 Lite - Gestionado - apilable |
Tipo de caja | Montaje en rack 1U |
Subtipo | Gigabit Ethernet |
Puertos | 24 x 10/100/1000 + 2 x 10 Gigabit SFP+ + 2 x 100/1000/10GBase-T |
Alimentación por Ethernet (PoE) | PoE |
Presupuesto PoE | 370 W |
Rendimiento | Capacidad: 95 Mpps ¦ Capacidad de conmutación: 128 Gbps ¦ Latencia (100 Mbps): 4.4 µs ¦ Latencia (1 Gbps): 2.2 µs ¦ Latencia (10 Gbps): 1.1 µs |
Capacidad | Entradas de dirección MAC: 16000 ¦ Rutas IPv4 (estático): 32 ¦ Rutas IPv6 (estático): 32 |
Tamaño de tabla de dirección MAC | 16000 entradas |
Admite carcasa Jumbo | 9216 bytes |
Protocolo de direccionamiento | Direccionamiento IP estático |
Protocolo de gestión remota | SNMP 1, SNMP 3, SNMP 2c, HTTP, HTTPS, RADIUS |
Método de autentificación | RADIUS |
Características | Control de flujo, soporte de DHCP, negociación automática, soporte ARP, soporte VLAN, señal ascendente automática (MDI/MDI-X automático), copia de puertos, soporte IPv6, mitad modo dúplex, modo dúplex completo, compatible con STP, compatible con ACL, TPM, LACP, CoS, EEE, BPDU Filter, VLAN de voz automática, LLDP-MED |
Cumplimiento de normas | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1s, IEEE 802.1ab (LLDP) |
Procesador | 1 x ARM: 800 MHz |
Indicadores de estado | Estado puerto, alimentación |
Parámetros de entorno | |
Temperatura mínima de funcionamiento | 0 °C |
Temperatura máxima de funcionamiento | 40 °C |
Ámbito de humedad de funcionamiento | 15 - 95% (40 °C) |
Temperatura mínima de almacenamiento | -40 °C |
Temperatura máxima de almacenamiento | 70 °C |
