Referencia: JL678A
Marca: HP
ARUBA 6100 24G 4SFP CPNT
HPE Aruba 6100 24G 4SFP+ Switch - Conmutador - Gestionado - 24 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+ - flujo de aire de lado a lado - montaje en rack
Alimentación | |
Dispositivo de alimentación | Fuente de alimentación eléctrica |
Potencia suministrada | 150.2 vatios |
Voltaje necesario | CA 120/230 V (50/60 Hz) |
Dimensiones y peso | |
Anchura | 25.4 cm |
Profundidad | 15.95 cm |
Altura | 4.39 cm |
Peso | 1.16 kg |
Diverso | |
MTBF (tiempo medio entre errores) | 95 años |
Cumplimiento de normas | VCCI, CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825-1, CNS 13438, EN 55024:2010, FCC CFR47 Part 15 A, ICES-003 issue 6 Class A, IEC 62368-1, UL 62368-1 Second Edition, CISPR 32 Class A, EN 62368-1:2014, CAN/CSA-C22.2 No. 60950-1, CISPR 35, EN 55035:2017, EN 55032:2015+AC:2016 Class A |
Expansión / Conectividad | |
Interfaces | 8 x 1000Base-T RJ-45 ¦ 2 x Gigabit LAN SFP |
Garantía del fabricante | |
Servicio y mantenimiento | Garantía limitada - de por vida ¦ Soporte técnico - asesoramiento telefónico - 90 días |
General | |
Tipo de dispositivo | Conmutador - 8 puertos - L2 + - Gestionado |
Tipo de caja | Montaje en rack 1U |
Subtipo | Gigabit Ethernet |
Puertos | 8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP |
Alimentación por Ethernet (PoE) | PoE+ |
Presupuesto PoE | 124 W |
Rendimiento | Capacidad: 14.88 Mpps ¦ Capacidad de conmutación: 20 Gbps ¦ Latencia (100 Mbps): 5.2 µs ¦ Latencia (1 Gbps): 3 µs |
Capacidad | Entradas de tabla de enrutamiento (estático): 32 |
Tamaño de tabla de dirección MAC | 8K de entradas |
Admite carcasa Jumbo | 9216 bytes |
Protocolo de direccionamiento | IGMPv2, IGMP, enrutamiento IPv4 estático, MSTP, RSTP, STP |
Protocolo de gestión remota | SNMP, RMON, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SCP, DHCP, IPv4, IPv6 |
Algoritmo de cifrado | SSL |
Método de autentificación | RADIUS |
Características | Control de flujo, soporte de DHCP, soporte ARP, concentración de enlaces, soporte VLAN, señal ascendente automática (MDI/MDI-X automático), snooping IGMP, copia de puertos, activable, soporte IPv6, mitad modo dúplex, modo dúplex completo, admite Spanning Tree Protocol (STP), admite Rapid Spanning Tree Protocol (RSTP), admite Multiple Spanning Tree Protocol (MSTP), soporte de Access Control List (ACL), Quality of Service (QoS), compatibilidad con Jumbo Frames, Trusted Platform Module (TPM), compatible con IPv4, Compatible con LACP, con LLDP, Protocolo de control de adición de enlaces (LACP), Class of Service (CoS), compatibilidad con SNMP, búfer de paquetes de 1,5 MB, Bridge protocol data unit (BPDU), LLDP-MED, Ethernet de eficiencia energética (EEE) |
Cumplimiento de normas | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.2af |
Procesador | 1 x ARM Cortex-A9: 800 MHz |
Memoria RAM | 512 MB |
Memoria Flash | 256 MB |
Parámetros de entorno | |
Temperatura mínima de funcionamiento | 0 °C |
Temperatura máxima de funcionamiento | 40 °C |
Ámbito de humedad de funcionamiento | 15 - 95% (sin condensación) |
Temperatura mínima de almacenamiento | -40 °C |
Temperatura máxima de almacenamiento | 70 °C |
Ámbito de humedad de almacenamiento | 15 - 95% (sin condensación) |
