Referencia: JL679A
Marca: HP
ARUBA 6100 12G CL4 2 CPNT
HPE Aruba 6100 12G Class4 PoE 2G/2SFP+ 139W Switch - Conmutador - Gestionado - 12 x 10/100/1000 (PoE+) + 2 x 1 Gigabit / 10 Gigabit SFP+ + 2 x 1000Base-T - montaje en rack - PoE+ (139 W)
Alimentación | |
Dispositivo de alimentación | Transformador eléctrico externo |
Voltaje necesario | CA 120/230 V (50/60 Hz) |
Consumo eléctrico en funcionamiento | 11 vatios |
Dimensiones y peso | |
Anchura | 25.4 cm |
Profundidad | 15.95 cm |
Altura | 4.39 cm |
Peso | 820 g |
Diverso | |
MTBF (tiempo medio entre errores) | 178 años |
Cumplimiento de normas | VCCI, CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1, EN 60825-1, CNS 13438, EN 55024:2010, FCC CFR47 Part 15 A, ICES-003 issue 6 Class A, UL 62368-1 Second Edition, CISPR 32 Class A, EN 62368-1:2014, EN 55032:2015+AC:2016, CISPR 35, SSL, IEC 62368-1: 2014 Second Edition, EN 55035:2017 |
Expansión / Conectividad | |
Interfaces | 8 x 10/100/1000 Base-T RJ-45 ¦ 2 x Gigabit LAN SFP |
Garantía del fabricante | |
Servicio y mantenimiento | Garantía limitada - de por vida |
General | |
Tipo de dispositivo | Conmutador - 10 puertos - L3 - Gestionado |
Tipo de caja | Sobremesa |
Subtipo | Gigabit Ethernet |
Puertos | 8 x 10/100/1000 + 2 x Gigabit SFP |
Rendimiento | Capacidad de conmutación: 20 Gbps ¦ Capacidad: 14.88 Mpps ¦ Latencia (100 Mbps): 5.2 µs ¦ Latencia (1 Gbps): 3 µs |
Capacidad | Puertos de agregación de enlace: 8 ¦ Rutas IPv4 (estático): 32 ¦ VLAN compatibles: 256 ¦ Access Control Entries (ACEs) per ACL: 480 ¦ Tamaño del búfer del paquete: 1,5 MB |
Tamaño de tabla de dirección MAC | 8.000 entradas |
Admite carcasa Jumbo | 9216 bytes |
Protocolo de direccionamiento | Direccionamiento IP estático |
Protocolo de gestión remota | SNMP 1, RMON, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, RADIUS |
Algoritmo de cifrado | SSL |
Método de autentificación | RADIUS |
Características | Control de flujo, soporte de DHCP, soporte ARP, soporte VLAN, señal ascendente automática (MDI/MDI-X automático), snooping IGMP, soporte IPv6, mitad modo dúplex, modo dúplex completo, compatible con STP, compatible con MSTP, compatible con ACL, QoS, TPM, con LLDP, LACP, Energy Efficient Ethernet, CoS, BPDU Filter |
Cumplimiento de normas | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az |
Procesador | 1 x ARM Cortex-A9: 800 MHz |
Memoria RAM | 512 MB SDRAM |
Memoria Flash | 256 MB |
Indicadores de estado | Estado puerto, alimentación |
Parámetros de entorno | |
Temperatura mínima de funcionamiento | 0 °C |
Temperatura máxima de funcionamiento | 40 °C |
Ámbito de humedad de funcionamiento | 15 - 95% (40 °C) |
Temperatura mínima de almacenamiento | -40 °C |
Temperatura máxima de almacenamiento | 70 °C |
Ámbito de humedad de almacenamiento | 15 - 95% (60 °C) |
